Parabolic Mirror

Share:
Product Details

The traditional manual method is adopted to process the lager diameter parabolic and hyperbolic lens with BK7 (ZK N4 or Zerodur) material, use knife-edge instrument for test, with high processing accuracy, and the diameter can be within 900mm.surface accuracy could be less than 1/40 lambda.


MaterialBK7, ZK N4 ,Zerodur ect.
Diameter tolerance+0.0/-0.15mm
Diameter≤900mm
Aspherical surfaceParabolic, Hyperbolic
Focal length tolerance±2%
Clear aperture≥90%
RMS Irregularity1/40λ
Surface Quality60-40
Bevel0.25 mm × 45°
CoatingMetal reflection coating/Dielectric reflection coating
